L&T DU125H MCCB 125A (100-125A) 2 Pole 30kA Thermal Magnetic | CM91198OOLO

Name: L&T DU125H MCCB 125A 2P CM91198OOLO - Manibhadra Enterprises
Brand: L&T
SKU: CM91198OOLO
Price: 5664.71 INR
Availability: InStock

₹5,664.71 Incl. of Taxes -37%Original price was: ₹7620.00.Current price is: ₹4800.60.+ GST ₹864.11 (18%)

+ GST (18%): ₹864.11
Total payable: ₹5664.71

Product image is for illustration purpose only – the photo shows a different rating of the same model.
L&T / Lauritz Knudsen DU125H MCCB, catalog no. CM91198OOLO
125A (100-125A), 2 Pole, 30kA @ 415V AC breaking capacity (Ics = 100% of Icu)
Adjustable thermal 0.8-1.0 x In, fixed magnetic 9 x In
GST invoice on every order | Same-day dispatch in Bengaluru for orders before 4 PM
Bulk and project rates on WhatsApp: +91 78160 62494

Order on Whatsapp

Add to wishlist

SKU: CM91198OOLO Categories: L&T MCCB, MCCB Tag: 2 Pole

Description
Additional information

Description

Note: the product photo is for illustration purpose only – it shows a different rating of the same model. The unit supplied is exactly the catalog number and rating on this page.

Looking for the L&T DU125H MCCB 125A 2 Pole? This is the genuine Lauritz Knudsen (formerly L&T Switchgear) DU series moulded case circuit breaker, catalog number CM91198OOLO, made for feeder, incomer and sub-distribution protection in commercial buildings, industries and OEM panels. We stock it at our Chamrajpet shop in Bengaluru with a GST invoice on every order, same-day dispatch for orders placed before 4 PM (Monday to Saturday), and delivery across all of Bengaluru including outskirts. Free store pickup is available. For project and bulk rates, WhatsApp us on +91 78160 62494.

Breaking capacity is 30 kA at 415V AC (65 kA at 240V AC for the 2 pole version, built in the 3 pole frame size), with Ics = 100% of Icu. The DU range gives you an adjustable thermal (overload) setting from 0.8 to 1.0 times In – this unit covers 125A (100-125A) – with a fixed magnetic short-circuit trip at 9 times the rated current (1125A here). That adjustability lets you trim the overload trip to the actual load and cable size during commissioning.

Spreader terminals are not included with this catalog number – if your panel needs them for cable termination (35 mm mm2 lugs), add the matching DU125H 2 pole spreader link set and, for panel-door operation, the direct or extended rotary handle from the Frequently Bought Together section below. One set covers one MCCB. Phase barriers are supplied with the unit.

Practical panel-builder details: no load-line bias, so supply and load can connect to either side; clear ON / TRIP / OFF indication; suitable for isolation; conforms to IS/IEC 60947-2, IEC 60947-2 and EN 60947-2.

Note on branding: L&T Switchgear is now Lauritz Knudsen Electrical & Automation (renamed in May 2024). Depending on stock, the unit may carry either the L&T or Lauritz Knudsen name. The catalog number, specifications and quality are identical.

📋 Technical Specifications

Parameter	Value
Brand	L&T / Lauritz Knudsen
Part Number / SKU	CM91198OOLO
Category	MCCB (Moulded Case Circuit Breaker)
Series	DU125H
Current Rating (In)	125 A
Poles	2 Pole (in 3 Pole frame size)
Breaking Capacity (Icu)	30 kA @ 415V AC; 65 kA @ 240V AC (2P: Icu @ 240V AC)
Service Breaking Capacity (Ics)	100% of Icu
Release Type	Thermal-Magnetic (adjustable thermal, fixed magnetic)
Thermal (Overload) Setting	Adjustable 0.8 – 1.0 x In (set 125A (100-125A))
Magnetic (Short Circuit) Setting	Fixed, 9 x In (1125 A for this 125A unit)
Rated Operational Voltage (Ue)	415V AC, 50/60 Hz
Rated Insulation Voltage (Ui)	800 V
Impulse Withstand Voltage (Uimp)	8 kV
Utilization Category	A
Standard	IS/IEC 60947-2, IEC 60947-2, EN 60947-2
Terminal Capacity	35 mm² cable with lug (link ≤17 mm)
Mechanical / Electrical Life	40,000 / 4,000 operations
Dimensions (W x D x H)	75 x 60 x 130 mm
Weight	0.6 kg
IP Rating / Isolation	IP40 (front), suitable for isolation

⚡ Key Features

Genuine L&T / Lauritz Knudsen DU125H MCCB – catalog no. CM91198OOLO
125A, 2 Pole, 30 kA breaking capacity at 415V AC (Ics = 100% of Icu)
Adjustable thermal release 0.8 – 1.0 x In; fixed magnetic trip at 9 x In
Phase barriers included; spreader terminals and rotary handles available separately below
No load-line bias – connect supply and load on either side
Clear ON / TRIP / OFF indication; suitable for isolation
GST invoice on every order; same-day dispatch in Bengaluru for orders before 4 PM

📄 Official Catalogue / Datasheet

Download the official L&T / Lauritz Knudsen DU/DY MCCB catalogue (covers DU125H technical data, trip curves, accessories and dimensions): DU/DY MCCB Catalogue (PDF, official)

❓ Frequently Asked Questions

Where can I use a 30 kA MCCB like the DU125H?

Use it where the prospective short-circuit level at the installation point is 30 kA or less – typically incomers and feeders in commercial and industrial distribution boards. Your panel designer or electrician works this out from the upstream transformer rating. If you need a higher fault level, the DU range goes up to 50 kA (DU400N) and the dsine DN range covers 25-100 kA – we stock both.

Can I adjust the trip settings on this MCCB?

Yes, partly – the DU125H has an adjustable thermal (overload) dial from 0.8 to 1.0 times In, so this 125A unit can be set anywhere in the 125A (100-125A) range. The magnetic short-circuit trip is fixed at 9 times the rated current (1125A on this unit). If you need finer electronic settings, look at the DN range with MTX microprocessor releases.

Are spreader terminals included with this MCCB?

No – CM91198OOLO is the without-spreader variant, which keeps the price lower. If your panel needs spreader terminals for 2 pole cable termination, add the matching DU125H 2 pole spreader link set from the Frequently Bought Together section below – one set covers one MCCB.

How fast can you deliver in Bengaluru?

Orders placed before 4 PM, Monday to Saturday, are dispatched the same day. We deliver across all of Bengaluru including outskirts like Sarjapur, Anekal and the airport side. Delivery charges are confirmed with you before dispatch. You can also pick up free from our Chamrajpet shop.

Do I get a GST invoice and what are the payment options?

Every order comes with a GST invoice suitable for ITC claims and project billing. Payment is prepaid through PhonePe – UPI, cards and netbanking are all accepted. For bulk quantities and project rates, WhatsApp us on +91 78160 62494.
